Saman water lubricated screw air compressor is a series of oil-free air compressors that use water as a lubricant, fundamentally solving the pollution problem that lubricating oil may cause to the environment. Compared to other oil-free air compressors, it has the advantages of simple structure, compactness, low speed, low vibration and noise, low exhaust temperature, high thermal efficiency, stable and reliable performance, and low specific power. It is the development trend of new oil-free compressors.

Its working principle is to continuously inject lubricating water into the compression chamber and bearings through the pressure difference generated by the compressor itself during the compression process. This design has the following characteristics:

The injected lubricating water can form a water film with a certain stiffness between the rotor, star wheel, and casing, and the star wheel is directly driven by the main rotor. Lubricating water directly lubricates the graphite bearings at both ends of the star wheel.

The injected lubricating water can achieve an airtight effect, which is superior to that of a typical dry screw compressor.

Lubricating water can absorb a large amount of compression heat, improve compression efficiency, and avoid the possibility of friction or jamming between the rotor, star wheel, and casing due to different thermal expansion coefficients.

Lubricating water can also reduce the noise generated by high-frequency compression.

Saman Machinery (Shanghai) Co., Ltd. uses pure water suitable for Qinyong standard for water lubricated air compressors, and the component materials used are standard grades 304 and 316 stainless steel.

SKF water lubricated special bearings, directly lubricated with water, have excellent oxidation resistance, corrosion resistance, and good lubrication performance.

The system uses purified water that is suitable for the standard usage, and the water circulates continuously in the system. Every 200 hours, the system automatically changes the water to ensure that the calcium content in the water remains stable at a low value, and the operating temperature of the host is not higher than 50 degrees, so there is no risk of scaling.

After air compression, its water content has reached saturation. The water content of compressed air is only related to temperature and has nothing to do with anything else. The compressed air temperature generated by water lubricated units is not higher than 50 degrees, and its water content is in a saturated state at 50 degrees. Due to the exhaust temperature of other types of compressors being higher than 50 degrees, the water content of compressed air in water lubricated units is lower than that of other types of compressors.

Operating costs:

Maintenance consumables: water filter, air filter.

Oil free safety: Due to the lack of lubricating oil in the host, the oil content in the discharged gas is 0.

Service life: Due to the maximum temperature of the host not exceeding 50 degrees, all components work within a small temperature difference range, resulting in a longer service life and lower failure rate.

Fire safety: The entire unit operates at temperatures below 50 degrees and is a water lubricated machine, so it will not produce spontaneous combustion or explosion, making it safe and reliable.

Since entering the Chinese market in 2011, Saman has used tens of thousands of screw compressors in China, all of which have received comprehensive technical support and services from Saman Company.

Saman has a warehouse and assembly factory in Shanghai, which can provide spot spare parts.

Users can receive free training (on-site), which includes:

1. Compressor operation training

2. Compressor system training

3. Maintenance training

4. Warranty

5. Spare parts ordering

·Our company responds to user requests 24 hours a day. During use, after receiving a distress message, we will send someone to the equipment site within 4 hours;

·From the date of equipment operation, the supplier's after-sales service personnel shall proactively conduct on-site inspections 4 times a year;

·Lifetime maintenance, timely inquire about the operation status of the equipment and any existing usage issues, try to meet the requirements of the demand as much as possible, and satisfy the users;

·Provide multiple service contracts (preventive maintenance, flexible maintenance, etc.)

·Saman Company guarantees that the goods are brand new, made of high-quality materials, processed with precision, and fully comply with all specifications and performance requirements stated in the contract. Under the conditions of correct installation, operation, and maintenance, the equipment warranty period is 12 months after the normal operation of the machine (with a five-year warranty for the main rotor).

·If there are any quality problems with the product during the warranty period, Saman Company will promptly repair or replace the relevant components free of charge. During the warranty period, the company provides free spare parts that need to be replaced. In case of any malfunction of the machine, our company shall provide free services (including providing accessories and labor) until the customer is satisfied

·Startup debugging

·Our company will dispatch qualified and experienced technicians to the site for installation inspection, equipment testing, and startup debugging.

Startup debugging content:

1. Inspect installation and work site

2. Inspect equipment such as compressors/dryers

3. Start up debugging/inspection and record the operation status

4. Dispatch training on operation and maintenance knowledge for operators
